马尔光学轴测量仪 BL-262111

商家货号：
品牌：马尔

产品说明：

The tasks of production metrology are growing with high-speed parallel to the innovations in the production process. By ever increasing accuracy requirements and declining cycle times in the production (turning, milling, grinding, etc.), rapid measurement directly on the production machine is inevitable. Measuring where the product is produced, with fast feedback to the production process in order to avoid waste. With the flexible shaft Measuring Machine MarShaft SCOPE 250 plus Mahr offers the right measurement solution for the fast, precise and fully automatic measurement of rotationally symmetrical workpieces in production.

The MarShaft SCOPE 250 plus has a high-precision roundness measuring axis (C) and a vertical measuring axis (Z) with a measuring range of 250 mm. The most important element is the modern, high-resolution CMOS matrix camera (live image) with a field of 1088 x 2048 pixels. The very high image acquisition of more than 120 frames per second enables fast measurement. Zoom functions allow the measurement of very small details that are difficult or impossible to inspect with conventional measuring.

产品特征：

Features at a glance:
*New, high-resolution CMOS matrix camera with 40 mm large live image field enables for quick scanning with more than 120 frames per second
*High accuracy for diameter and length measurement
*Extremely short measuring times due to high measuring speeds up to 200 mm/s
*With use of the Mahr software platform MarWin, all decades of experience in the fields of length, form, position and contour measurement available
*Very good entry price into the segment of small optical shaft measuring machines
